Descrizione di prodotto
LED Emergency Battery Pack Emergency Drivers 1.5h Emergency Time for Triproof Light Down Light Ceiling Light Highbay Light Panel Light
1.Meet most of safety standards for lighting
2.Standard CSA C22.2 NO.141 UL924
3.External lithium iron phosphate battery
4.Battery protections: over charge protection over discharge protection short circuit protection
5.Indicator shows a variety working modes
6.The batteries Meet 2000 cycles of standard CH and standard DCH
7.RoHS compliant
| Model NO. |
MF-SM-xxW |
| Input Voltage |
100~347Vac,50/60Hz |
| Input Current |
100mAmax. |
| Battery Charging Current |
250ma |
| Charging time |
≥24Hours |
| Output Current and Voltage |
15-55VDC/60-240VDC |
| Emergency Time |
≥1.5H |
| Output Power |
4W |
| Battery |
Li-Fep04 2000mAh-6.4V |
| Warranty |
5 Years |
| Ambient Temp |
0°C to 60°C |
| Trademark |
MF |
1.Listed North America UL cert.
2.Comply UL924 ordinances, CSA C22.2 No.141 in-site assembly
3.Constant power output
4.Comply emergency saving CEC ordinance
5.Charging and dis-charging protection function and over heat temp. protection
6.Mock-up electricity pause emergency testing function
7.Can be power off under emergency status
8.Indication light: city grid electricity
9.Seasonal self detect function
10.Protection functions: over voltage, short circuit, over load and open circuit
11.Metallic housing, comply EMC, FCC and C-tick ordinances
12.IP grade: IP20
Commercial Office Buildings
Provides code-compliant emergency lighting for hallways, stairwells and exit routes during power outages. Maintains illumination for safe evacuation.
Industrial Plants & Warehouses
Rugged design withstands harsh environments while providing emergency lighting for hazardous areas and manufacturing facilities.
Healthcare Facilities
Critical backup lighting for hospitals and clinics where uninterrupted lighting is essential for patient care and emergency procedures
Retail Stores & Shopping Malls
Maintains emergency aisle lighting and exit signage to guide customers to safety during power failures.
Residential High-Rise Buildings
Critical for apartment complexes to illuminate stairwells and common areas during blackouts. The 90-minute runtime exceeds most building code requirements for residential emergency lighting..
Hospitality Industry (Hotels & Resorts)
Ensures guest safety by maintaining emergency lighting in corridors, lobbies and fire exits during power disruptions. The self-testing feature provides automated compliance with safety regulations.
Installation Instructions
1:If it is used for the first time or it does not enter the normal working
state after being over-discharged, it is necessary to connect the main power
to activate the emergency power supply and charge it for 24 hours.
Please use the original emergency battery provided
2:When installing and using it, please keep it away from heat sources and only use
it within a certain working temperature range.
3:Should be stored in a cool, dry environment.
4:After prolonged storage, recharge at least once every 6 months as needed.
5:Emergency driver testing must be longer than 1min, don't press the testing button frequently.
LED and test button status:
LED INDICATOR
Green breathing pattern:charging mode
Green stable: battery fully charged
Red flashing: failure as below
Red flashing Once per second: Battery is not connected
Battery is defective
Red flashing four times a second :Load failure during emergency mode,
open circuit/short circuit
Green flashing: Emergency status one per second
TEST BUTTON
1:0S<Key≤2S,Enter a simulated state of emergency,the green indicator blinks once every second,keep emergency status for 10±1 seconds and back to normal status
2.In simulated emergency situations,Short press once to exit and return to the normal charging state
3.0S<Key≤1S,In the emergency state, the emergency state is turned off.
QUARTERLY SELF-TEST
when emergency driver is on power,every 180 days± 1 day automatically enter the emergency state,emergency duration until the battery is discharged,then return to power-on status.
