Casa ProdottiKit di emergenza LEDLED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light
LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light
LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light
Contattaci

LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light

Quantità di ordine minimo : 1 PCS Prezzo : USD
Imballaggi particolari : Cartucce Tempi di consegna : 5-8 giorni lavorativi
Termini di pagamento : L/C, T/T, D/A, D/P, Western Union, MoneyGram Capacità di alimentazione : 10000 pezzi/mese
Luogo di origine: Cina Marca: MF
Certificazione: CE, RoHS Numero di modello: MF-EMUFO-XXW-170

Informazioni dettagliate
Voltaggio di ingresso universale: 100-277VAC/347VAC 50/60Hz Corrente di ingresso CA: 200mamax
Potenza nominale introdotta: 12w massimo Voltaggio di uscita: 170
Potenza di emergenza: 25W/30W/40W Tempo di ricarica: 24 ore
Tempo di scarico: 90 minuti Batteria: Li-ione
Temperatura ambiente: 32 ~ 122 °F (0 ~ 50 °C) Peso: 5.10 libbre ((2.2kg)
Evidenziare:

Triproof Light LED Emergency Driver

,

IP66 LED Emergency Driver

,

Ballast LED Emergency Driver

Descrizione di prodotto

High Bay Light LiFePO4 Battery Back Up IP65 15W-3H/20W-2H/30W-1.5H Discharge Time Self-detect LED Emergency Driver Power Supply Emergency Conversion Kit

LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 0

LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 1

descriptions:


self-detect
constant power emergency output
apply to constant current driver external lighting products
LiFePO4 using together
battery: over-charge/discharge protection and short circuit protection
working environment: temp.: 0 to 60°C
IP65 standard
not suitable for high risk lighting environment
Accessories: integrated waterproof button and indicator light, remote control
3years warranty

Input voltage 220-240Vac, 50/60Hz
Input current 0.003A Max. @230Vac
Charging power:
5.0W max.
Power factor
>0.5
Emergency output Voltage
DC100-260V,DC300V Max.
Emergency output Current:
58-150mA/ 75-200mA/115-300mA
Case temperature
to 60ºC Max.
IP Rating IP 65
Warranty 3 Years
Battery Data Li-ion 2.6Ah 7.4V
Discharging time&Power 5W 3H





LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 2LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 3LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 4

LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 5

LED indicator:
Green breathing pattern: charging mode
Green stable: battery fully charged
Red flashing: failure as below
Red flashing Once per second: Battery is not connected
Battery is defective
Red flashing four times a second: Load failure during emergency mode, open circuit/short circuit
Green flashing: Emergency status one per second


Remote control:
1: 0S < Key ON ≤1S, Enter a simulated state of emergency, the green indicator blinks once every second
2: 0S < Key OFF ≤1S, In simulated emergency situations, return to the normal charging state
3: 0S < Key OFF ≤1S, In the emergency state, the emergency state is turned off.


Self-test:
When emergency driver is on power, every 180 days ±1 day automatically enter the emergency state, emergency duration until the battery is discharged, then return to power-on status

LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 6LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 7

LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 8



LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 9LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 10

LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 11

Application:
school,hospital,subway,train station,shoppingmall,supermarket,airport,office, factory,hotel,basement,parking lot,public place



LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 12LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 13LED Emergency Driver Battery Back Up IP66 Backup Ballast for High Bay Light Triproof Light 14
