Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures

Quantità di ordine minimo : 1 pezzo Prezzo : USD
Packaging Details : carton 280*45*28mm Tempi di consegna : 7 giorni lavorativi
Termini di pagamento : L/C, D/P, T/T Capacità di alimentazione : 10000pieces/month
Luogo di origine: Cina Marca: MF
Certificazione: CE ROHS Numero di modello: MF-EMUFO-XXW-170

Informazioni dettagliate

Corrente di ingresso: 200mamax Voltaggio di uscita: 170VDC
Tempo di ricarica Tempo di ricarica: 24 ore Battery: Li-ion
Peso: 5.10 libbre ((1.4kg) Voltaggio di ingresso: 100~347VAC,50/60Hz
Potenza nominale introdotta: massimo 12W. Potenza di emergenza: 25W/30W/40W
Tempo di scarico: 90 minuti Temperatura ambiente: 32~122 F ((0....+50 oC)
Evidenziare:

Outdoor Lighting Emergency Backup Ballast

,

25W Emergency Backup Ballast

,

30W Emergency Backup Ballast

Descrizione di prodotto

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w for Indoor Andoutdoor Lighting FixturesEmergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 0



Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 1

Model NO. MF-EMUFO-xxW-170
Input Voltage 100~347Vac,50/60Hz
Input Current 200mAmax.
Input Power Rating 12W max.
Output Voltage 170Vdc
Emergency Power 25W/30W/40W
Recharge Time 24Hrs
Discharge Time 90 minute
Battery Li-ion
Warranty 5 Years
Ambient Temp 32~122 F(0....+50 ºC)
Weight 5.10 lbs(2.2kg)

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 2

 CAUTION:

1.During AC operation, remember no touch or remove any wires in case of electric shock

2.During emergency operation, before touching and disconnecting the wires, remember to press the test button again to make the led lamp and indicator light off to avoid electric shock

3.The voltage input to the dimmable wires(DIM+,DIM-) of emergency LED driver must less than 20Vdc

4.For emergency LED driver of MF -EMUFO-25W-170 battery work with LED lamp not more than 150W,for MF -EMUFO-30W-170/MF -EMUFO-40W-170 must work with LED lamp less than 300W

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 3

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 4

1.Listed North America UL cert.
2.Comply UL924 ordinances, CSA C22.2 No.141
3.in-site assembly
4.With 0/1-10V dimming
5.With infra red wireless remote control
6.Constant power output
7.High voltage output
8.Comply emergency saving CEC ordinance
9.Charging and dis-charging protection function
10.and over heat temp. protection
11.Mock-up electricity pause emergency testing function
12.Can be power off under emergency status
13.Indication light: city grid electricity
14.Seasonal self detect function
15.Protection functions: over voltage, short circuit, over
16.load and open circuit
17.Metallic housing, comply EMC, FCC and C-tick ordinances
18.IP grade: IP40

Model No. Output Voltage Emergency Power Battery Type
MF-EMUFO-25W-170 170Vdc 25W Li-ion
MF-EMUFO-30W-170 30W Li-ion
MF-EMUFO-40W-170 40W Li-ion
Indicator Light

1.AC Operation, indicator light will keep on

2.Emergency Operation, indicator light flash slowly (light on for 1 seconds, light off for 1 seconds)

3.In a failure, indicator light flash quickly (light on for 0.02 seconds,light off for 0.02 seconds
Model Test Switch Operation Indicator Status Comment & Solutions
AC MODE Pressed the ON button on the remote 0.5s ON andis OFF(slowflashing) The battery is under emergency test
Press OFF on the remote again to toggle the battery charge
EMERGENCY MODE (1) NO Pressed 0.5s ON andis OFF(slowflashing) Battery is automatically conhucting a emergency until Battery is fully discharged
EMERGENCY MODE (2) Pressed the OFF button on the remote OFF Battery is turned off
SELF-TEST
The emergency LED driver contains a control/monitor circuit which will perform 30-second discharge test once a month and a fully discharge test once a year. At this time, the unit simulate an AC power failure and automatically switch to emergency mode. During routine testing, the unit will monitor the operation of the LED load,battery voltage, and emergency duration, if the unit detect any problems, the indicator will fash quickly.
Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 5
Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 6

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 7

Commercial Office Buildings

Provides code-compliant emergency lighting for hallways, stairwells and exit routes during power outages. Maintains illumination for safe evacuation.

Healthcare Facilities

Critical backup lighting for hospitals and clinics where uninterrupted lighting is essential for patient care and emergency procedures.

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 8

Educational Institutions

Ensures safe evacuation paths in schools and universities during emergencies with 90 minutes of reliable backup power.

Industrial Plants & Warehouses

Rugged design withstands harsh environments while providing emergency lighting for hazardous areas and manufacturing facilities.

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 9Retail Stores & Shopping Malls

Maintains emergency aisle lighting and exit signage to guide customers to safety during power failures.

Public Transportation Hubs

Essential for airports, subway stations and bus terminals where continuous lighting is critical for passenger safety and evacuation procedures.

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 10

Hospitality Industry (Hotels & Resorts)

Ensures guest safety by maintaining emergency lighting in corridors, lobbies and fire exits during power disruptions. The self-testing feature provides automated compliance with safety regulations.

Residential High-Rise Buildings

Critical for apartment complexes to illuminate stairwells and common areas during blackouts. The 90-minute runtime exceeds most building code requirements for residential emergency lighting.

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 11

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 12





Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 13          Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 14

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 15

As a leading manufacturer of LED light product MING FENG LIGHTING CO.,LTD established in year 2009 and has more than 14 years experience in exporting LED lighting products. Our company established a quality management system in accordance with the ISO9001 standard. Products are CE,CB,ROHS,SAA,ETL,DLC certified. And Ming Feng has expanded its business to many countries to Europe,America,Southeast Asia and etc.
In order to provide our customers with attractive lighting fixtures,optimal energy saving and thoughtful lighting solutions,Ming Feng hired the professional,Dialux lighting designer,and providing the OEM & ODM service for all the partners around the world. Our designer and engineer always pay full attention to them in the field of high quality standard at reasonable and competitive price,fast delivery,trust and honest services etc.
Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 16

Emergency Backup Ballast Emergency Drivers Integrated Internal Li Battery 25W 30W 40w For Indoor Outdoor Lighting Fixtures 17



Q1: Are you a manufacturer?
MF: Yes, we are a manufacturer with our own factory. We have over 14 years of experience in research and development, as well as manufacturing, and we operate based on ISO quality management since 2009.

Q2: Can I order a sample of the LED Light?
MF: Yes, we welcome sample orders to test and check the quality of our products. Mixed samples are also acceptable.

Q3: What is the lead time for the LED Light?
MF: For sample orders, the lead time is 3-7 days, and for mass production orders, it is 15-25 days. The exact lead time depends on the order quantities.

Q4: How do you ship the finished products?
MF: We offer optional shipping methods such as by SEA, AIR, or Express (DHL, UPS, FedEx, TNT, etc.).

Q5: Can I print my logo on the LED Light?
MF: Yes, we provide OEM service to our customers. We can help to make the label and color box according to your requirements.

Q6: How do I proceed with an order for the LED Light?
MF: Firstly, please let us know your detailed requirements and application environment. Secondly, we will recommend some suitable products and solutions to you based on your request. Thirdly, after confirming all the details, customers will issue a purchase order and make the payment to confirm, and then we will start production and arrange shipment.

Q7: How do you handle defective products?
MF: All of our products are produced in strict quality control systems, and the defective rate is less than 0.2% according to our shipment records. We offer a 5-year warranty for this product. If there is any defect during the warranty period, please provide pictures or videos of the defective lights in working situations, and we will ship new lights to you within a few days or together with your next order.
